Michigan
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 27,668 lb |
|---|---|
| Fuel Capacity | 52.9 gal |
| Tire Size | 20.5-25 |
| Hydraulic System Fluid Capacity | 51.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 233 in |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 45 A |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 9.3 gal |
| Engine Oil Capacity | 4.0 gal |
| Static Tipping Load - Bucket | 20,481 lb |
| Front Diff Fluid Capacity | 7.3 gal |
| Rear Diff Fluid Capacity | 7.3 gal |
| Static Tipping Load - Forks | 11,023 lb |
Engine
| Engine Model | 6 BT 5.9 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 145.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 410 lb-ft |
Hydraulic System
| Raise Time | 6.4 s |
|---|---|
| Lower Time | 3.5 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 2,970 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 121 in |
| Wheelbase | 119 in |
| Width Over Tires | 100 in |
| Hinge Pin - Max Height | 151 in |
| Reach at Max Height and Dump | 42 in |
| Length w/ Bucket on Ground | 283 in |
| Dump Clearance at Max Lift | 111 in |
| Max Lift Height | 145 in |
| Fork Tine Length | 49 in |
| Height at Hook Max Reach | 64 in |
| Hook Max Reach - standard | 130 in |
| Hook Max Reach - extended | 215 in |
Transmission
| Max Speed - Forward | 20.4 mph |
|---|---|
| Max Speed - Reverse | 20.4 mph |
| Transmission Type | Clark C270 powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 2.30 yd³ |
| Breakout Force | 26,380 lb |
