Mustang
Hitachi
ZX30U-5
Mini Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 10,528 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 43.9 gal/min |
| Hydraulic System Relief Valve Pressure | 3,480 psi |
Engine
| Engine Model | 4TNV88-PNS |
|---|---|
| Displacement | 134 in³ |
| Gross Power | 48.0 hp |
| Net Power | 38.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 102 in |
| Tail Swing Radius | 40 in |
| Width to Outside of Tracks | 78 in |
| Removal Counterweight Clearance | 17 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 16 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 12,787 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 142 in |
|---|---|
| Max Reach Along Ground | 233 in |
| Max Vertical Wall Digging Depth | 104 in |
| Max Loading Height | 210 in |
| Shipping Length of Unit | 206 in |
| Max Cutting Height | 238 in |
| Shipping Height of Unit | 102 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 7,599 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 152 in |
|---|---|
| Max Cutting Height | 248 in |
| Max Loading Height | 154 in |
| Max Vertical Wall Digging Depth | 115 in |
| Max Reach Along Ground | 244 in |
| Shipping Height of Unit | 102 in |
| Shipping Length of Unit | 206 in |
