Mustang
7503ZT
- Operating Weight
- 16,193 lb
- Max Digging Depth
- 159 in
- Max Digging Depth
- 170 in
- Net Power
- 57.0 hp
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 16,193 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 55.4 gal/min |
| Hydraulic System Relief Valve Pressure | 3,118 psi |
Engine
| Engine Model | 4TNV98-VNS |
|---|---|
| Displacement | 203 in³ |
| Gross Power | 69.0 hp |
| Net Power | 57.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 106 in |
| Tail Swing Radius | 46 in |
| Width to Outside of Tracks | 90 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 18 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 17,196 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 159 in |
|---|---|
| Max Reach Along Ground | 274 in |
| Max Loading Height | 178 in |
| Max Vertical Wall Digging Depth | 134 in |
| Max Cutting Height | 261 in |
| Shipping Length of Unit | 256 in |
| Shipping Height of Unit | 106 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.50 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 10,184 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 170 in |
|---|---|
| Max Vertical Wall Digging Depth | 146 in |
| Max Cutting Height | 269 in |
| Max Loading Height | 186 in |
| Max Reach Along Ground | 284 in |
| Shipping Length of Unit | 256 in |
| Shipping Height of Unit | 106 in |
