Mustang
Tata Hitachi
EX70
Excavator
39 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 17,548 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 63.0 gal/min |
| Hydraulic System Relief Valve Pressure | 3,553 psi |
Engine
| Engine Model | 4TNV98-VNS |
|---|---|
| Displacement | 203 in³ |
| Gross Power | 69.0 hp |
| Net Power | 57.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 108 in |
| Tail Swing Radius | 61 in |
| Width to Outside of Tracks | 90 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 18 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 19,401 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 169 in |
|---|---|
| Max Reach Along Ground | 277 in |
| Max Loading Height | 191 in |
| Max Vertical Wall Digging Depth | 144 in |
| Max Cutting Height | 276 in |
| Shipping Length of Unit | 259 in |
| Shipping Height of Unit | 108 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.50 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 180 in |
|---|---|
| Max Vertical Wall Digging Depth | 156 in |
| Max Cutting Height | 294 in |
| Max Loading Height | 282 in |
| Max Reach Along Ground | 288 in |
| Shipping Length of Unit | 259 in |
| Shipping Height of Unit | 108 in |
