Mustang
Case
21D
Wheel Loader
43 specifications
Mustang
ML28
- Operating Weight
- 7,055 lb
- Bucket Capacity - heaped
- 1.50 yd³
- Gross Power
- 48.0 hp
- Net Power
- 39.0 hp
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,055 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| Tire Size | 12.0 - 18 |
| Static Tipping Weight | 5,181 lb |
| Turning Radius | 134 in |
| Rear Axle Oscillation | 38 ° |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 48.0 hp |
| Net Power | 39.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 13.7 gal/min |
|---|---|
| Relief Valve Setting | 3,336 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 93 in |
| Wheelbase | 70 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 11 in |
| Length with Bucket on Ground | 189 in |
| Hinge Pin - Max Height | 120 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Max Speed - Reverse | 12.4 mph |
| Transmission Type | Hydrostatic |
Bucket
| Bucket Capacity - heaped | 1.50 yd³ |
|---|---|
| Bucket Capacity - struck | 0.90 yd³ |
| Dump Clearance at Max Raise | 91 in |
| Breakout Force | 6 lb |
| Bucket Width | 66 in |
