434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 16,316 lb |
|---|
Engine
| Net Power | 110.0 hp |
|---|
Transmission
| Max Speed | 20.0 mph |
|---|
General Specifications
| Operating Weight lbs (kg) | 16,316 (7,401) — Starting 2009 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 15.3 (4.7) — Starting 2011 Model Year |
| Lift Capacity lbs (kgs) | 7,925 (3,595) — Starting 2010 Model Year |
| Loading Height ft (m) | 12.7 (3.87) — Starting 2010 Model Year |
| 4th Gear Fwd mph (kmh) | 20 (32.2) — Starting 2010 Model Year |
| Backhoe Loading Height ft. (m) | 12.7 (3.87) — Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 20 (32.2) — Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 14,109 (6,400) — Starting 2010 Model Year |
| Digging Depth ft (m) | 15.3 (4.7) — Starting 2010 Model Year |
| Loader SAE HP (kw) | 110 (82) — Starting 2011 Model Year |
| Loader Lift Capacity lbs. (kg) | 7,925 (3,595) — Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 14,109 (6,400) — Starting 2009 Model Year |
| SAE HP (KW) | 110 (82) — Starting 2010 Model Year |
| Weight lbs (kg) | 16,316 (7,401) — Starting 2010 Model Year |
Backhoe
| Dig Depth | 183 in |
|---|---|
| Load Height | 152 in |
Loader
| Lift Capacity | 7,925 lb |
|---|---|
| Bucket Breakout Force | 14,109 lb |
