434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight 4wd | 17,491 lb |
|---|---|
| Operating Weight | 18,289 lb |
| Operating Weight 2wd | 16,755 lb |
| Fuel Capacity | 35.7 gal |
| Hydraulic System Fluid Capacity | 31.2 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Tire Size Front - 2wd / 4wd | 24 inches |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.6 gal |
| Alternator Supplied Amperage | 90 A |
| Turning Radius | 170 in |
| Max Weight | 19,555 lb |
Engine
| Engine Model | 445T/M2 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 110.0 hp |
| Net Power | 107.3 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 384 lb-ft |
Hydraulic System
| Pump Flow Capacity | 42.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,045 psi |
| Pump Type | Dual Gear |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 88 in |
| Transport Width | 95 in |
| Transport Length | 281 in |
| Height to Top of Suspended Cab | 118 in |
Transmission
| Max Speed | 24.4 mph |
|---|---|
| Max Speed - Reverse | 8.3 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 28 inches |
|---|
Backhoe
| Dig Depth | 180 in |
|---|---|
| Reach From Swivel | 230 in |
| Dig Depth - Extended | 221 in |
| Load Height - Extended | 256 in |
| Bucket Dig Force | 12,808 lb |
| Reach From Swivel - Extended | 274 in |
| Reach at Load Height - Extended | 120 in |
| Bucket Dig Force - Extended | 12,809 lb |
Loader
| Bucket Capacity | 1.50 yd³ |
|---|---|
| Lift Capacity | 7,464 lb |
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 12,165 lb |
| Bucket Width | 95 in |
| Reach at Max Dump Height | 32 in |
| Dig Depth | 5 in |
