New Holland
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Operating Weight 4wd | 18,135 lb |
|---|---|
| Operating Weight | 16,028 lb |
| Operating Weight 2wd | 17,350 lb |
| Fuel Capacity | 35.5 gal |
| Hydraulic System Fluid Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Tire Size Front - 2wd / 4wd | 12-16.5 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.7 gal |
| Alternator Supplied Amperage | 90 A |
Engine
| Engine Model | FPT 445TA/E3 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 97.0 hp |
| Net Power | 91.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | New Holland |
| Bore | 4 in |
| Stroke | 5 in |
| Net Max Torque | 334 lb-ft |
Hydraulic System
| Pump Flow Capacity | 40.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,045 psi |
| Pump Type | Open center |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 86 in |
| Transport Width | 90 in |
| Transport Length | 288 in |
| Height to Top of Suspended Cab | 114 in |
Transmission
| Max Speed | 20.0 mph |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Power shuttle |
Tires & Wheels
| Rear Tires Size | 19.5L-24 |
|---|
General Specifications
| Operating Weight lbs (kg) | 16,008 (7,261) Starting 2009 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.4 (4.4) Starting 2011 Model Year |
| Lift Capacity lbs (kgs) | 8,095 (3,672) Starting 2010 Model Year |
| Loading Height ft (m) | 12.0 (3.67) Starting 2010 Model Year |
| 4th Gear Fwd mph (kmh) | 20 (32.2) Starting 2010 Model Year |
| Backhoe Loading Height ft. (m) | 12.0 (3.67) Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 20 (32.2) Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 15,212 (6,900) Starting 2010 Model Year |
| Digging Depth ft (m) | 14.4 (4.4) Starting 2010 Model Year |
| Loader SAE HP (kw) | 97 (72) Starting 2011 Model Year |
| Loader Lift Capacity lbs. (kg) | 8,095 (3,672) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 15,212 (6,900) Starting 2009 Model Year |
| SAE HP (KW) | 97 (72) Starting 2010 Model Year |
| Weight lbs (kg) | 16,008 (7,261) Starting 2010 Model Year |
Backhoe
| Dig Depth | 173 in |
|---|---|
| Reach From Swivel | 204 in |
| Dig Depth - Extended | 215 in |
| Load Height - Extended | 176 in |
| Bucket Dig Force | 12,591 lb |
| Reach From Swivel - Extended | 263 in |
| Load Height | 144 in |
| Bucket Dig Force - Extended | 13,254 lb |
Loader
| Lift Capacity | 6,856 lb |
|---|---|
| Clearance at Max Dump Height | 95 in |
| Bucket Breakout Force | 14,212 lb |
| Bucket Width | 88 in |
| Reach at Max Dump Height | 46 in |
