New Holland
Case IH
2388
Combine
12 specifications
New Holland
CX8090
- Operating Weight w/o Attachment
- 34,832 lb
- Fuel Capacity
- 265.0 gal
- Displacement
- 629 in³
- Power
- 400.0 hp
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight w/o Attachment | 34,832 lb |
|---|---|
| Fuel Capacity | 265.0 gal |
| Transmission Type | Hydrostatic drive |
| Number of Gears | 4 |
Engine
| Displacement | 629 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Power | 400.0 hp |
Dimensions
| Overall Length | 356 in |
|---|---|
| Width Over Tires | 174 in |
| Height to Top of Isomount Cab | 156 in |
Cleaning System
| Total Cleaning Area | 10,075 in³ |
|---|---|
| Cleaning Fan Speed - High | 900 rpm |
| Cleaning Fan Speed - Low | 475 rpm |
| Self Leveling | — |
Grain Handling
| Grain Tank Capacity | 3,072.0 gal |
|---|---|
| Unloading Speed | 3.2 bu/sec |
| Unloading Auger Length | 252 in |
Separating
| Separating Area | 11,083 in³ |
|---|---|
| Separator Length | 145 in |
Threshing
| Rotor Diameter | 28 in |
|---|---|
| Rotor Length | 62 in |
| Rotor Speed - High | 905 rpm |
| Rotor Speed - Low | 305 rpm |
| Concave Area | 1,829 in³ |
| Beater Grate Area | 450 in³ |
