New Holland
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 3,240 lb |
|---|---|
| Fuel Capacity | 4.0 gal |
| Hydraulic Pump Flow Capacity | 3.9 gal/min |
| Hydraulic System Fluid Capacity | 4.5 gal |
| Hydraulic System Relief Valve Pressure | 2,988 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 20 A |
Engine
| Engine Model | 3TNE68-YB |
|---|---|
| Displacement | 48 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 11.9 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 91 in |
| Length of Track on Ground | 61 in |
| Tail Swing Radius | 24 in |
| Removal Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 3 psi |
|---|---|
| Track Gauge | 26 in |
| Max Travel Speed | 2.3 mph |
| Shoe Size | 1 in |
| Drawbar Pull | 4,160 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 84 in |
|---|---|
| Max Reach Along Ground | 145 in |
| Max Vertical Wall Digging Depth | 70 in |
| Max Loading Height | 102 in |
| Shipping Length of Unit | 132 in |
| Max Cutting Height | 144 in |
| Shipping Height of Unit | 88 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.10 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|---|
| Swing Torque | 281 lb-ft |
