New Holland

EH15.B

Mini Excavator

Operating Weight
3,241 lb
Max Digging Depth
84 in
Net Power
11.9 hp
All mini excavators
New Holland EH15.B Mini Excavator
1 / 5
Image 1 of 5
Image: ebay.com

Specifications

30 data points

Operating Specifications

Operating Specifications specifications
Operating Weight3,241 lb
Fuel Capacity4.0 gal
Hydraulic Pump Flow Capacity2.5 gal/min
Hydraulic System Fluid Capacity4.5 gal
Hydraulic System Relief Valve Pressure2,988 psi
Operating Voltage12 V
Alternator Supplied Amperage20 A

Engine

Engine specifications
Engine Model-3TNE68-YB
Displacement48 in³
Power Measured @2,000 rpm
Net Power11.9 hp
Number of Cylinders3

Dimensions

Dimensions specifications
Ground Clearance7 in
Height - Top of Cab100 in
Length of Track on Ground48 in
Tail Swing Radius24 in
Width to Outside of Tracks48 in
Removal Counterweight Clearance18 in

Undercarriage

Undercarriage specifications
Ground Pressure3 psi
Max Travel Speed2.3 mph
Shoe Size1 in
Drawbar Pull4,160 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth84 in
Max Reach Along Ground149 in
Max Vertical Wall Digging Depth70 in
Max Loading Height101 in
Max Cutting Height144 in

Bucket

Bucket specifications
Reference Bucket Capacity0.10 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm
Swing Torque281 lb-ft
