New Holland
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 5,370 lb |
|---|---|
| Fuel Capacity | 16.0 gal |
| Hydraulic System Fluid Capacity | 4.0 gal |
| Tire Size | 10 X 16.5 |
| Engine Oil Fluid Capacity | 2.0 gal |
| Chain Box Fluid Capacity - each side | 1.7 gal |
| Shipping Weight - Empty | 5,071 lb |
Engine
| Engine Model | N844T |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,900 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,750 rpm |
| Max Torque | 109 lb-ft |
| Engine Make | ISM |
| Stroke | 4 in |
| Bore | 3 in |
Hydraulic System
| Displacement-Standard aux | 1 in³ |
|---|---|
| Pump Flow Capacity | 15.6 gal/min |
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear |
| Dump Time | 1.9 s |
| Lower Time | 2.1 s |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 37 in |
| Width Over Tires | 49 in |
| Reach at Max Lift and Dump | 19 in |
| Height - Top of ROPS/FOPS | 76 in |
| Length with Bucket | 120 in |
| Length w/o Bucket | 96 in |
| Bucket hinge pin fully raised | 112,008 in |
Loader
| Operating Load Rating | 1,500 lb |
|---|---|
| Operating Width | 60 in |
| Tipping load (ISO 14397) | 3,001 lb |
