New Holland
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 14,010 lb |
|---|
General Specifications
| Operating Weight lbs (kg) | 14,010 (6,354) — Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 6,765 (3,070) — Starting 2004 Model Year |
| Loading Height ft (m) | 12 (3.7) — Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 19.8 (32) — Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 12,897 (5,850) — Starting 2004 Model Year |
| Digging Depth ft (m) | 14.4 (4.4) — Starting 2004 Model Year |
| SAE Net hp (kW) | 70 (52) — Starting 2004 Model Year |
Backhoe
| Max Digging Depth | 173 in |
|---|---|
| Loading Height | 144 in |
Loader
| Lift Capacity | 6,765 lb |
|---|---|
| SAE - Net | 70.0 hp |
| Breakout Force | — |
Travel Speed
| 4th Gear Fwd | 19.8 mph |
|---|
