New Holland
T6.080
- Operating Weight
- 12,346 lb
- Displacement
- 412 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 155.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 12,346 lb |
|---|---|
| Fuel Capacity | 67.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 12,212 lb |
| 3 Point Hitch Type | Category II/IIIN |
| Alternator Supplied Amperage | 120 A |
| Hydraulic System Fluid Capacity | 16.3 gal |
| Engine Oil Capacity | 16.0 gal |
Engine
| Displacement | 412 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 155.0 hp |
| Net Power | 135.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| PTO Power | 135.0 hp |
Hydraulic System
| Pump Flow Capacity | 37.0 gal/min |
|---|
Dimensions
| Height - Top of Cab | 115 in |
|---|---|
| Wheelbase | 106 in |
Transmission
| Transmission Type | 18x6 Power Command |
|---|
Production
| Series | T6000 Series |
|---|---|
| Years Manufactured | 2,007 – 2,012 |
Axles
| Axle Diameter | 4 in |
|---|---|
| Axle Length | 98 in |
