New Holland
T8.390
- Operating Weight
- 23,534 lb
- Displacement
- 531 in³
- Power Measured @
- 2,000 rpm
- Gross Power
- 335.3 hp
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 23,534 lb |
|---|---|
| Fuel Capacity | 168.3 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 20,128 lb |
| Tire Size Front - 2wd / 4wd | 710/70R42 |
| Oil System Fluid Capacity | 5.3 gal |
Engine
| Engine Model | Cursor 9 |
|---|---|
| Displacement | 531 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 335.3 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged / Intercooled |
| Max Torque | 1,232 lb-ft |
| Engine Make | Iveco / FPT |
| PTO Power | 289.7 hp |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 42.6 gal/min |
|---|---|
| Maximum operating pressure | 3,046 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Overall Length | 230 in |
| Overall Width | 101 in |
| Height - Top of ROPS/FOPS | 133 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 18 |
| Transmission Type | Manual / Full Power-Shift |
| Number of Reverse Gears | 4 |
Tires & Wheels
| Rear Tires Size | 540/65R34 |
|---|
Production
| Series | T8 Series |
|---|---|
| Years Manufactured | 2,011 – 2,014 |
