New Holland
Yanmar
Ke - 140
Tractor
22 specifications
New Holland
TC24D
- Operating Weight
- 1,723 lb
- Displacement
- 69 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 24.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 1,723 lb |
|---|---|
| Fuel Capacity | 5.3 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,265 lb |
| Turning Radius | 97 in |
Engine
| Displacement | 69 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 24.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 19.5 hp |
Hydraulic System
| Pump Flow Capacity | 7.7 gal/min |
|---|
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 81 in |
| Wheelbase | 57 in |
| Overall Length | 9 in |
| Tire Size | Front 5x12 Rear 11.2x24 |
| Width Outside Frame | 46 in |
Transmission
| Max Speed | 10.0 mph |
|---|---|
| Number of Forward Gears | 9 |
| Transmission Type | Manual |
| Number of Reverse Gears | 3 |
Production
| Series | Boomer TC Series |
|---|---|
| Years Manufactured | 1,999 – 2,003 |
