New Holland
Fendt
817
Tractor
23 specifications
New Holland
TG305
- Operating Weight
- 20,371 lb
- Displacement
- 507 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 304.0 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 20,371 lb |
|---|---|
| Fuel Capacity | 180.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,969 lb |
Engine
| Displacement | 507 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 304.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | CNH |
| PTO Power | 254.8 hp |
| Bore | 5 in |
| Stroke | 5 in |
Hydraulic System
| Pump Flow Capacity | 38.6 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
Dimensions
| Wheelbase | 121 in |
|---|
Transmission
| Number of Forward Gears | 18 |
|---|---|
| Transmission Type | Manual / Full Power-Shift |
| Number of Reverse Gears | 4 |
Production
| Series | TG II Series |
|---|---|
| Years Manufactured | 2,006 – 2,007 |
Comparable machines
Other tractors in a similar weight class.
