New Holland
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 128.2 gal |
|---|
Engine
| Engine Model | 474 |
|---|---|
| Displacement | 476 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 6 |
| Engine Make | Ford |
| Power | 240.0 hp |
Dimensions
| Wheelbase | 137 in |
|---|---|
| Transport Width | 192,915 in |
| Transport Height | 159 in |
| Transport Length | 427 in |
| Turning Radius | 269 in |
| Unloader clearance | 134 in |
| Unloader reach | 95 in |
Tires & Wheels
| Rear Tires Size | 16/70 - 20 |
|---|---|
| Front Tires Size | 30.5L - 32 R1 |
Cleaning System
| Cleaning Fan Speed - High | 960 rpm |
|---|---|
| Cleaning Fan Speed - Low | 500 rpm |
| Cleaning system width | 61 in |
Grain Handling
| Grain Tank Capacity | 2,141.1 gal |
|---|---|
| Unloading Discharge Height | 159 in |
| Unloading Auger Length | 166 in |
| Unloading auger diameter | 12 in |
Separating
| Separator Type | Transverse mounted with angled spike teeth |
|---|---|
| Width | 61 in |
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Speed - High | 1,150 rpm |
| Rotor Speed - Low | 380 rpm |
| Concave Area | 1,474 in³ |
| Beater Grate Area | 1,046 in³ |
| Rotor Type | High inertia transverse mounted hardened and chromed rasp bars |
| Rotor width | 61 in |
HEADER
| Width - Table | 150 in |
|---|---|
| Auger diameter | 24 in |
| HEADER Type | Centre feed |
| Conveyor speed | 9,576.0 mph |
| Lowering time | 3.5 |
