New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 30,446 lb |
|---|---|
| Fuel Capacity | 66.9 gal |
| Tire Size | 23.5-25 RT-3B |
| Hydraulic System Fluid Capacity | 51.0 gal |
| Static Tipping Weight | 25,574 lb |
| Operating Voltage | 24 V |
| Turning Radius | 248 in |
| Engine Oil Fluid Capacity | 4.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Cooling System Fluid Capacity | 10.6 gal |
| Transmission Fluid Capacity | 10.6 gal |
Engine
| Engine Model | CNH F4HE0684J |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 197.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbo aftercooler |
Hydraulic System
| Pump Flow Capacity | 54.5 gal/min |
|---|---|
| Raise Time | 5.6 s |
| Lower Time | 3.3 s |
| Dump Time | 2.4 s |
| Relief Valve Setting | 3,626 psi |
| Pump Type | load sensing circuit closed centre |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 128 in |
| Reach at Max Lift and Dump | 48 in |
| Length with Bucket on Ground | 306 in |
| Hinge Pin - Max Height | 157 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 16.1 mph |
| Transmission Type | PowerShift CounterShaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.70 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
| Bucket Width | 109 in |
