Pel-Job

EB150XR

Mini Excavator

Operating Weight
3,450 lb
Max Digging Depth
88 in
Gross Power
19.0 hp
Net Power
15.0 hp
All mini excavators
Pel-Job EB150XR Mini Excavator
1 / 5
Image 1 of 5
Image: truck1.eu

Specifications

44 data points

Operating Specifications

Operating Specifications specifications
Operating Weight3,450 lb
Fuel Capacity5.6 gal
Hydraulic Pump Flow Capacity11.4 gal/min
Hydraulic System Fluid Capacity6.1 gal
Hydraulic System Relief Valve Pressure2,466 psi
Operating Voltage12 V

Engine

Engine specifications
Engine ModelL3E
Displacement58 in³
Power Measured @2,800 rpm
Gross Power19.0 hp
Net Power15.0 hp
Torque Measured @1,850 rpm
Max Torque40 lb-ft

Dimensions

Dimensions specifications
Ground Clearance8 in
Height - Top of Cab86 in
Length of Track on Ground42 in
Tail Swing Radius44 in
Width to Outside of Tracks40 in
Removal Counterweight Clearance18 in

Undercarriage

Undercarriage specifications
Max Travel Speed1.3 mph
Shoe Size9 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth88 in
Max Reach Along Ground143 in
Max Vertical Wall Digging Depth60 in
Max Loading Height98 in
Shipping Length of Unit144 in
Max Cutting Height134 in
Shipping Height of Unit89 in

Bucket

Bucket specifications
Reference Bucket Capacity0.10 yd³
Maximum Bucket Capacity0.10 yd³
Minimum Bucket Capacity0.10 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth97 in
Max Cutting Height141 in
Max Loading Height103 in
Max Vertical Wall Digging Depth70 in
Max Reach Along Ground152 in
Shipping Height of Unit89 in
Shipping Length of Unit144 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth100 in
Max Cutting Height148 in
Max Loading Height107 in
Max Reach Along Ground157 in
Max Vertical Wall Digging Depth77 in
