Ponsse
Caterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Operating Weight | 54,013 lb |
|---|---|
| Fuel Capacity | 105.7 gal |
| Hydraulic System Fluid Capacity | 92.5 gal |
Engine
| Engine Model | OM926LA |
|---|---|
| Gross Power | 321.9 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 959 lb-ft |
Dimensions
| Height - Top of Cab | 152 in |
|---|---|
| Overall Width | 119 in |
| Shipping Length - non tilt | 347 in |
| Forward Tilt | 20 ° |
Undercarriage
| Ground Clearance | 25 in |
|---|
Boom
| Max Reach w/ Head | 433 in |
|---|
Drive System
| Tire Size - front | 600/65-34 |
|---|---|
| Tire Size - rear | 600/55-26.5 |
