New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 23,590 lb |
|---|---|
| Tire Size | 17.5x25 |
| Static Tipping Weight | 14,837 lb |
| Turning Radius | 117 in |
Engine
| Engine Model | 6BT5.9-C120 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 116.7 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 113 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 280 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 16.0 mph |
| Transmission Type | Electrohydrostatic |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.39 yd³ |
|---|---|
| Dump Clearance at Max Raise | 117 in |
| Bucket Width | 100 in |
