Roadtec AstecRoadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight w/ Screed | 36,300 lb |
|---|---|
| Operating Weight w/o Screed | 31,000 lb |
| Operating Weight | 31,000 lb |
| Fuel Capacity | 89.9 gal |
| Hydraulic System Fluid Capacity | 48.9 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 5.1 gal |
| Alternator Supplied Amperage | 115 A |
Engine
| Displacement | 403 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 174.0 hp |
| Number of Cylinders | 6 |
| Make | Cat |
Dimensions
| Wheelbase | 91 in |
|---|---|
| Transport Height | 121 in |
| Tire Size | 16.00-24 |
| Width w/ Hopper Open | 126 in |
Hopper/Paver
| Paving Speed - max | 3.1 mph |
|---|---|
| Travel Speed - max | 8.0 mph |
| Auger Diameter | 14 in |
| Paving Speed | 3.1 mph |
