Roadtec Astec
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight w/ Screed | 104,499 lb |
|---|---|
| Operating Weight w/o Screed | 90,390 lb |
| Operating Weight | 41,000 lb |
| Fuel Capacity | 120.0 gal |
| Hydraulic System Fluid Capacity | 5.1 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 71.1 gal |
| Alternator Supplied Amperage | 115 A |
Engine
| Displacement | 439 in³ |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 225.0 hp |
| Number of Cylinders | 6 |
| Make | Cat |
Dimensions
| Length of Track on Ground | 126 in |
|---|---|
| Transport Width | 131 in |
| Transport Height | 141 in |
| Track Width | 18 in |
| Width w/ Hopper Open | 131 in |
Hopper/Paver
| Paving Speed - max | 1.9 mph |
|---|---|
| Travel Speed - max | 7.5 mph |
| Auger Diameter | 16 in |
| Paving Speed | 1.9 mph |
