Roadtec Astec
Dynapac
PL2000S
Cold Planer
19 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight - Full Load | 58,000 lb |
|---|---|
| Operating Speed | 1.7 mph |
| Travel Speed | 3.2 mph |
| Fuel Capacity | 290.0 gal |
| Water Spray System Fluid Capacity | 599.9 gal |
| Shipping Weight - Empty | 49,850 lb |
| Hydraulic System Fluid Capacity | 84.0 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | QSX-15 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 600.0 hp |
Dimensions
| Shipping Height | 102 in |
|---|---|
| Shipping Length | 306 in |
| Shipping Width | 93 in |
| Operating Length | 545 in |
| Max Operating Height | 185 in |
Track
| Number of Track Units | 4 |
|---|---|
| Front Track Width | 12 in |
| Rear Track Width | 12 in |
Conveyor System
| Discharge Conveyor Width | 32 in |
|---|---|
| Discharge Conveyor Swing (R/L) | 60 ° |
Rotary Cutter
| Cutting Width | 76 in |
|---|---|
| Cutting Depth | 13 in |
| Tool Spacing | 1 in |
