Rostselmash
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight w/o Attachment | 24,361 lb |
|---|---|
| Fuel Capacity | 142.7 gal |
Engine
| Engine Model | YAMZ-236ND |
|---|---|
| Aspiration | turbocharged |
| Power | 206.6 hp |
Dimensions
| Wheelbase | 149 in |
|---|---|
| Overall Length | 647 in |
| Width Over Tires | 141 in |
| Height to Top of Isomount Cab | 158 in |
Cleaning System
| Total Cleaning Area | 5,565 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,000 rpm |
| Cleaning Fan Speed - Low | 380 rpm |
Feeding
| Conveyor Width | 252 in |
|---|---|
| Conveyor Speed | 49 rpm |
Grain Handling
| Grain Tank Capacity | 1,585.4 gal |
|---|---|
| Unloading Speed | 1.2 bu/sec |
| Unloading Discharge Height | 131 in |
Separating
| Separating Area | 7,750 in³ |
|---|---|
| Separator Type | 4 key straw walker |
| Separator Length | 162 in |
Threshing
| Rotor Diameter | 32 in |
|---|---|
| Rotor Length | 47 in |
| Rotor Speed - High | 945 rpm |
| Rotor Speed - Low | 420 rpm |
| Concave Area | 1,699 in³ |
