Sakai

SV201D

Smooth Drum Roller

Operating Weight
9,590 lb
Max Speed
4.6 mph
Drum Width
54 in
Gross Power
60.4 hp
All smooth drum rollers
Sakai SV201D Smooth Drum Roller
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight9,590 lb
Max Speed4.6 mph
Fuel Capacity26.5 gal
Operating Width54 in
Operating Voltage12 V
Hydraulic System Fluid Capacity10.1 gal

Engine

Engine specifications
Engine ModelB3.3-C
Displacement199 in³
Power Measured @2,200 rpm
Gross Power60.4 hp

Dimensions

Dimensions specifications
Ground Clearance12 in
Height - Top of Cab102 in
Wheelbase8 in
Overall Length14 in
Overall Width54 in

Tires & Wheels

Tires & Wheels specifications
Tires11.2-20-6PR

Drum

Drum specifications
Drum Width54 in
Drum Diameter39 in
Vibration Frequency 130 vpm
Vibration Frequency1,800 vpm
Centrifugal Force - Low16,186 lb
Frequency30 vpm
