Sakai

SV400D

Smooth Drum Roller

Operating Weight
15,873 lb
Max Speed
6.3 mph
Drum Width
67 in
Gross Power
81.9 hp
All smooth drum rollers
Sakai SV400D Smooth Drum Roller
1 / 5
Image 1 of 5
Image: belialat.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight15,873 lb
Max Speed6.3 mph
Fuel Capacity47.6 gal
Operating Voltage24 V
Hydraulic System Fluid Capacity13.3 gal

Engine

Engine specifications
Engine ModelA-4BG1
Displacement264 in³
Power Measured @2,300 rpm
Gross Power81.9 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab113 in
Wheelbase9 in
Overall Length16 in
Overall Width74 in

Tires & Wheels

Tires & Wheels specifications
Tires16.9-24-10PR (OR)

Drum

Drum specifications
Drum Width67 in
Drum Diameter51 in
Vibration Frequency 140 vpm
Centrifugal Force - High26,528 lb
Vibration Frequency 230 vpm
Centrifugal Force - Low20,907 lb
