Sakai
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 33,069 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 79.3 gal |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 16.5 gal |
Engine
| Engine Model | BB-6BG1TRJ diesel engine |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 166.3 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 113 in |
| Wheelbase | 10 in |
| Overall Length | 19 in |
| Overall Width | 91 in |
Tires & Wheels
| Tires | 23.1-26-8PR (OR) |
|---|
Drum
| Drum Width | 84 in |
|---|---|
| Drum Diameter | 60 in |
| Vibration Frequency 1 | 37 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 61,823 lb |
| Vibration Frequency 2 | 28 vpm |
| Centrifugal Force - Low | 49,458 lb |
| Nominal Amplitude - Low | 0 in |
