Sakai
Dynapac
CG233HF
Smooth Drum Roller
19 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 15,653 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 31.8 gal |
| Operating Width | 58 in |
| Operating Voltage | 24 V |
Engine
| Engine Model | W04D-H |
|---|---|
| Displacement | 245 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 75.1 hp |
| Make | Hino WO4D-H |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 110 in |
| Wheelbase | 10 in |
| Overall Length | 14 in |
| Overall Width | 64 in |
| Turning Radius - Inside | 139 in |
Drum
| Drum Diameter | 42 in |
|---|---|
| Vibration Frequency 1 | 67 vpm |
| Centrifugal Force - High | 15,512 lb |
| Vibration Frequency 2 | 50 vpm |
| Vibration Frequency | 4,020 vpm |
| Centrifugal Force - Low | 13,938 lb |
Comparable machines
Other smooth drum rollers in a similar weight class.
