Salford
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight w/o Attachment | 23,854 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Transmission Type | hydrostatic |
| Number of Gears | 3 |
Engine
| Engine Model | 6.7 I (*) |
|---|---|
| Power Measured @ | 2,100 rpm |
| Power | 241.0 hp |
| Power Boost Power | 242.0 hp |
Dimensions
| Overall Length | 322 in |
|---|---|
| Width Over Tires | 126 in |
| Height to Top of Isomount Cab | 156 in |
Cleaning System
| Total Cleaning Area | 6,696 in³ |
|---|---|
| Self Leveling | 0 |
Grain Handling
| Grain Tank Capacity | 1,849.7 gal |
|---|---|
| Unloading Speed | 2.1 bu/sec |
Separating
| Separating Area | 8,355 in³ |
|---|---|
| Separator Type | Rotary |
| Separator Length | 23 in |
| Discharge Grate Area | 9,347 in³ |
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Length | 51 in |
| Rotor Speed - High | 1,140 rpm |
| Rotor Speed - Low | 440 rpm |
