Salford
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight w/o Attachment | 27,029 lb |
|---|---|
| Fuel Capacity | 132.1 gal |
| Transmission Type | hydrostatic |
| Number of Gears | 4 |
Engine
| Power Measured @ | 2,100 rpm |
|---|---|
| Power | 258.0 hp |
| Power Boost Power | 272.0 hp |
Dimensions
| Overall Length | 357 in |
|---|---|
| Width Over Tires | 119 in |
| Height to Top of Isomount Cab | 155 in |
Cleaning System
| Total Cleaning Area | 8,370 in³ |
|---|---|
| Cleaning Fan Speed - High | 900 rpm |
| Cleaning Fan Speed - Low | 475 rpm |
Grain Handling
| Grain Tank Capacity | 2,008.0 gal |
|---|---|
| Unloading Speed | 3.2 bu/sec |
Separating
| Separating Area | 7,657 in³ |
|---|---|
| Separator Type | rotary |
Threshing
| Rotor Diameter | 30 in |
|---|---|
| Rotor Length | 51 in |
| Rotor Speed - High | 905 rpm |
| Rotor Speed - Low | 305 rpm |
| Concave Area | 1,519 in³ |
