Salford
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight w/o Attachment | 25,133 lb |
|---|---|
| Fuel Capacity | 158.6 gal |
| Transmission Type | hydrostatic |
| Number of Gears | 4 |
Engine
| Engine Model | NH 675 TA/CB |
|---|---|
| Power Measured @ | 2,100 rpm |
| Power | 299.0 hp |
Dimensions
| Overall Length | 320 in |
|---|---|
| Width Over Tires | 157 in |
| Height to Top of Isomount Cab | 157 in |
Cleaning System
| Total Cleaning Area | 10,075 in³ |
|---|---|
| Cleaning Fan Speed - High | 860 rpm |
| Cleaning Fan Speed - Low | 435 rpm |
Grain Handling
| Grain Tank Capacity | 2,509.8 gal |
|---|---|
| Unloading Speed | 2.1 bu/sec |
Separating
| Separator Type | rotary |
|---|
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Length | 62 in |
| Rotor Speed - High | 1,140 rpm |
| Rotor Speed - Low | 385 rpm |
| Concave Area | 1,333 in³ |
| Beater Grate Area | 930 in³ |
