Hitachi
EX135USR
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 30,600 lb |
|---|---|
| Fuel Capacity | 68.7 gal |
| Hydraulic Pump Flow Capacity | 68.7 gal/min |
| Hydraulic System Relief Valve Pressure | 4,552 psi |
Engine
| Engine Model | 4BTA3.9-C |
|---|---|
| Power Measured @ | 2,100 rpm |
| Net Power | 99.0 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 259 lb-ft |
Dimensions
| Ground Clearance | 26 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 120 in |
| Tail Swing Radius | 88 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 235 in |
|---|---|
| Max Reach Along Ground | 350 in |
| Max Loading Height | 254 in |
| Max Cutting Height | 352 in |
| Shipping Length of Unit | 307 in |
| Shipping Height of Unit | 120 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
