New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 22,708 lb |
|---|---|
| Fuel Capacity | 52.9 gal |
| Tire Size | 17.5x25 |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Static Tipping Weight | 18,298 lb |
| Operating Voltage | 24 V |
| Turning Radius | 185 in |
| Rear Axle Oscillation | 28 ° |
| Alternator Supplied Amperage | 50 A |
| Cooling System Fluid Capacity | 9.1 gal |
| Transmission Fluid Capacity | 6.5 gal |
Engine
| Engine Model | 65T5.9-C |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 126.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 50.2 gal/min |
|---|---|
| Raise Time | 5.8 s |
| Lower Time | 3.3 s |
| Dump Time | 1.1 s |
| Relief Valve Setting | 2,840 psi |
| Pump Type | vane pumps |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 113 in |
| Width Over Tires | 98 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 269 in |
| Hinge Pin - Max Height | 144 in |
Transmission
| Max Speed - Forward | 20.7 mph |
|---|---|
| Max Speed - Reverse | 13.0 mph |
| Transmission Type | Countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Bucket Capacity - struck | 1.90 yd³ |
| Dump Clearance at Max Raise | 111 in |
| Breakout Force | 23,810 lb |
| Bucket Width | 97 in |
