Skyjack
Snorkel
S1930
Aerial Lift
25 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Dimensions
| Overall Length | 54 in |
|---|---|
| Overall Width | 31 in |
| Gradeability | 30.0 % |
| Stowed Height | 71 in |
| Turning Radius - Outside minimum | 55 in |
Performance
| Operating Weight | 2,130 lb |
|---|---|
| Tire Size | 12 x 4 x 8 |
| Tire Fill/Type | Solid |
Platform
| Max Platform Weight Capacity | 500 lb |
|---|---|
| Platform Inner Length | 37 in |
| Platform Inner Width | 27 in |
| Max Working Height | 259 in |
| Lift Time | 20.0 s |
| Lower Time | 18.0 s |
| Drive Speed - Platform Elevated | 0.5 mph |
| Drive Speed - Platform Lowered | 2.5 mph |
| Wind Rating | 28.0 mph |
| Maximum no of Persons | 2 |
| Local Floor Load - no load | 92 psi |
| Local Floor Load - with rated load | 120 psi |
