COMPACT 2032E
Aerial Lift
26 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Engine
| Battery Amp Hours | — |
|---|---|
| Charger Amps | 27 |
| Maximum Ground Bearing Pressure | 101 psi |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Wheelbase | 54 in |
| Overall Length | 69 in |
| Overall Width | 33 in |
| Overall Height | 80 in |
| Turning Radius | 67 in |
Brakes & Steering
| Brakes Type | Multi-Disc Friction |
|---|
Performance
| Operating Weight | 2,630 lb |
|---|---|
| Tire Size | 12 x 4 in |
| Hydraulic System Fluid Capacity | 4.5 gal |
| Gradeability | 25.0 % |
| Drive Speed - Platform Lowered | 2.0 mph |
| Drive Speed - Platform Elevated | 0.5 mph |
| Hydraulic Pump Type | Fixed Displacement Gear |
| Maximum Drive Height | 228 in |
| Drive System | Hydraulic Front Wheel |
Platform
| Max Platform Height | 228 in |
|---|---|
| Max Working Height | 300 in |
| Lift Time | 25.0 s |
| Lower Time | 26.0 s |
| Height of Rails | 41 in |
| Platform Capacity - Unrestricted | 550 lb |
| Platform Capacity - Extension | 250 lb |
