Haulotte
Snorkel
S1930
Aerial Lift
25 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Engine
| System Voltage | 24 V |
|---|---|
| Battery Amp Hours | 225 |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 73 in |
| Overall Length | 8 in |
| Overall Width | 33 in |
| Turning Radius | 85 in |
| Gradeability | 23.0 % |
| Stowed Width | 33 in |
| Stowed Height | 80 in |
| Boom Type/Size | 26.40 ft (8.05 m) |
| Height w/ Rails | 80 in |
Tires & Wheels
| Tire Size | 15x5 |
|---|
Performance
| Operating Weight | 3,649 lb |
|---|---|
| Max Speed | 2.1 mph |
| Tire Size | 15x5 |
| Hydraulic System Fluid Capacity | 7.1 gal |
Capacity
| Platform Capacity | 11 lb |
|---|
Platform
| Max Platform Height | 245 in |
|---|---|
| Max Platform Weight Capacity | 770 lb |
| Platform Inner Length | 91 in |
| Platform Inner Width | 32 in |
| Max Working Height | 317 in |
| Lift Time | 26.0 s |
| Deck Extension | 36 in |
| Lower Time | 37.0 s |
