Spra-Coupe
Top Air
TA 1600 120ft
Sprayer
7 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 9,259 lb |
|---|---|
| Fuel Capacity | 25.1 gal |
| Hydraulic Fluid Capacity | 3.5 gal |
| Engine Oil Capacity | 2.1 gal |
| Cooling System Fluid Capacity | 2.6 gal |
| Alternator Supplied Amperage | 5 A |
| Transmission Fluid Capacity | 0.8 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | XUD11AT |
|---|---|
| Displacement | 127 in³ |
| Power Measured @ | 3,600 rpm |
| Gross Power | 87.2 hp |
| Number of Cylinders | 4 |
| Engine Make | Peugeot |
| Gross Torque | 154 lb-ft |
Dimensions
| Wheelbase | 134 in |
|---|---|
| Overall Length | 236 in |
| Transport Width | 91 in |
| Transport Height | 131 in |
| Tire Size | Front - 9.00-24 SL Rear 12.4-24 FS |
Transmission
| Max Speed | 19.9 mph |
|---|---|
| Transmission Type | Borg-Warner T-5 neutral start interlock |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
Boom
| Max Boom Width | 709 in |
|---|---|
| Max Adjustable Height | 76 in |
| Min Adjustable Height | 21 in |
| Nozzle Spacing | 20 in |
| Number of Nozzles - max | 36 |
