Stavostroj

V900

Smooth Drum Roller

Operating Weight
23,627 lb
Drum Width
87 in
Gross Power
149.0 hp
All smooth drum rollers
Stavostroj V900 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: sunbeltrentals.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight23,627 lb

Engine

Engine specifications
Engine Model6BT5.9
Displacement360 in³
Power Measured @2,200 rpm
Gross Power149.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab119 in
Wheelbase9 in
Overall Length17 in
Overall Width88 in
Drum Diameter - Front60 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1x26.8PLY

Drum

Drum specifications
Drum Width87 in
Drum Diameter59 in
Vibration Frequency 129 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High46,311 lb
Vibration Frequency 235 vpm
Static Linear Load13 lb-ft
Centrifugal Force - Low39,342 lb
Nominal Amplitude - Low0 in
