Sumitomo
Roadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight w/o Screed | 27,999 lb |
|---|
Engine
| Engine Model | 4D34-TE1 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 93.9 hp |
Dimensions
| Wheelbase | 110 in |
|---|---|
| Transport Width | 98 in |
| Transport Height | 102 in |
| Tire Size | 22x14x16 15.5R25 |
| Length w/ Screed | 248 in |
| Width w/ Hopper Open | 236 in |
Hopper/Paver
| Paving Width - max | 236 in |
|---|---|
| Paving Speed - max | 0.9 mph |
| Travel Speed - max | 9.4 mph |
| Auger Diameter | 13 in |
| Paving Thickness - max | 12 in |
