Svedala
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight w/ Screed | 36,817 lb |
|---|---|
| Operating Voltage | 24 V |
Engine
| Engine Model | TCD 2013 L06 |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 190.0 hp |
Dimensions
| Wheelbase | 98 in |
|---|---|
| Transport Width | 101 in |
| Transport Height | 122 in |
| Tire Size | Front 560/300 Rear 14.00-R25 XGC |
| Track Width | 100 in |
| Width w/ Hopper Open | 134 in |
| Length w/o Screed | 257 in |
Hopper/Paver
| Paving Width - max | 319 in |
|---|---|
| Paving Speed - max | 1.1 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 12.2 mph |
| Auger Diameter | 15 in |
| Paving Thickness - max | 12 in |
