Tadano

ATF 45-3

All Terrain Crane

Gross Power
326.0 hp
Max Lift Capacity
100,000 lb
Max Speed - Forward
49.7 mph
Transport Width
111 in
All all terrain cranes
Tadano ATF 45-3 All Terrain Crane
1 / 5
Image 1 of 5
Image: crane-locator.com

Specifications

31 data points

Operating Specifications

Operating Specifications specifications
Operating Weight61,685 lb
Tire Size20.5R25
Carrier Fuel Capacity79.3 gal
Operating Voltage24 V
Number of Axels3
Alternator Supplied Amperage100 A

Dimensions

Dimensions specifications
Transport Width111 in
Transport Height143 in
Transport Length411 in
Width w/ Outriggers Extended248 in
Upper Structure Tail Swing Radius149 in
Carrier Length362 in

Transmission

Transmission specifications
Max Speed - Forward49.7 mph
Max Speed - Reverse5.0 mph
Transmission TypeZF AS-Tronic type 12AS2302
Number of Forward Gears12
Number of Reverse Gears2

Boom

Boom specifications
Max Lift Capacity100,000 lb
Number of Sections5
Max Height @ Max Raise Angle - no jib1,338 in
Min Height @ Max Raise Angle354 in
Max Elevating Angle80 °
Swing Speed3 rpm
Min Working Radius108 in
Max Working Radius1,200 in

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power326.0 hp
Displacement439 in³
Max Torque959 lb-ft
Torque Measured @1,200 rpm
MakeTadano
Power Measured @2,300 rpm
