Takeuchi
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 3,524 lb |
|---|---|
| Fuel Capacity | 5.5 gal |
| Hydraulic Pump Flow Capacity | 8.7 gal/min |
| Hydraulic System Fluid Capacity | 8.9 gal |
| Hydraulic System Relief Valve Pressure | 2,844 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 0.8 gal |
| Cooling System Fluid Capacity | 0.9 gal |
Engine
| Engine Model | 3TNV70-STB |
|---|---|
| Displacement | 52 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 13.5 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 38 lb-ft |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 90 in |
| Length of Track on Ground | 37 in |
| Tail Swing Radius | 44 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 95 in |
|---|---|
| Max Reach Along Ground | 154 in |
| Max Vertical Wall Digging Depth | 76 in |
| Max Loading Height | 113 in |
| Shipping Length of Unit | 150 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
