Terex
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Fuel Capacity | 64.8 gal |
|---|---|
| Tire Size | 23.5 R 25 |
| Engine Oil Capacity | 5.9 gal |
| Cooling System Fluid Capacity | 14.1 gal |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 7.4 gal |
Engine
| Engine Model | 6CTA8.3-C |
|---|---|
| Displacement | 8 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 255.0 hp |
| Net Power | 244.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged and aftercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 750 lb-ft |
Weights
| Total Empty | 43,299 lb |
|---|---|
| Front Axle - empty | 21,804 lb |
| Total Loaded | 98,414 lb |
| Rear Axle - empty | 10,626 lb |
| Front Axle - loaded | 33,852 lb |
| Rear Axle - loaded | 32,110 lb |
| Center Axle - empty | 10,869 lb |
| Center Axle - loaded | 32,452 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 196 in |
| Overall Length | 372 in |
| Overall Width | 121 in |
| Overall Height | 134 in |
| Dump Height | 231 in |
| Dump Ground Clearance | 26 in |
Transmission
| Max Speed | 28.0 mph |
|---|---|
| Transmission Type | ZF 6WG 200 Powershift |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 55,116 lb |
|---|---|
| Dump Angle | 65 ° |
| Raise Time | 13.0 s |
| Lower Time | 9.0 s |
| Capacity - Heaped | 19.70 yd³ |
| Capacity - Struck | 16.40 yd³ |
