Terex
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Fuel Capacity | 65.0 gal |
|---|---|
| Tire Size | 23.5 R 25 |
| Engine Oil Capacity | 10.5 gal |
| Cooling System Fluid Capacity | 14.3 gal |
| Hydraulic System Fluid Capacity | 52.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 13.5 gal |
Engine
| Engine Model | MTA11-C300 |
|---|---|
| Displacement | 659 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 300.0 hp |
| Net Power | 287.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and aftercooled |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 1,015 lb-ft |
Weights
| Total Empty | 45,316 lb |
|---|---|
| Front Axle - empty | 23,336 lb |
| Total Loaded | 104,841 lb |
| Rear Axle - empty | 10,957 lb |
| Front Axle - loaded | 31,857 lb |
| Rear Axle - loaded | 36,509 lb |
| Center Axle - empty | 11,023 lb |
| Center Axle - loaded | 36,476 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 196 in |
| Overall Length | 372 in |
| Overall Width | 111 in |
| Overall Height | 134 in |
| Dump Height | 233 in |
| Dump Ground Clearance | 26 in |
Transmission
| Max Speed | 28.0 mph |
|---|---|
| Transmission Type | ZF 6WG 250 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 59,525 lb |
|---|---|
| Dump Angle | 65 ° |
| Raise Time | 13.0 s |
| Lower Time | 9.0 s |
| Capacity - Heaped | 21.01 yd³ |
| Capacity - Struck | 17.09 yd³ |
