Terex
A300
- Operating Weight
- 531,314 lb
- Max Lift Capacity
- 66,139 lb
- Max Speed - Forward
- 22.4 mph
- Gross Power
- 143.5 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 531,314 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Tire Size | 14R24 |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | F4GE9584D*J601 |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 143.5 hp |
| Aspiration | Turbo supercharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 457 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 11 in |
| Transport Width | 100 in |
| Transport Height | 134 in |
| Transport Length | 380 in |
| Width w/ Outriggers Extended | 217 in |
| Upper Structure Tail Swing Radius | 124 in |
| Carrier/Base Length | 231 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | DNDA series 20000: powershift with torque converter |
Boom
| Max Lift Capacity | 66,139 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 948 in |
| Min Height @ Max Raise Angle | 318 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 5 |
| Min Operating Radius | 119 in |
| Max Operating Radius | 946 in |
