Terex
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
Terex
CR452
- Operating Weight w/ Screed
- 38,495 lb
- Paving Width - max
- 335 in
- Gross Power
- 205.0 hp
- Length w/ Screed
- 234 in
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight w/ Screed | 38,495 lb |
|---|---|
| Operating Weight w/o Screed | 30,595 lb |
| Fuel Capacity | 72.2 gal |
| Hydraulic System Fluid Capacity | 75.1 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 6.7 gal |
| Alternator Supplied Amperage | 105 A |
Engine
| Engine Model | QSB5.9 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 205.0 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Wheelbase | 89 in |
|---|---|
| Transport Width | 125 in |
| Transport Height | 104 in |
| Tire Size | front 16x22in rear 16-ply 23.1x26 in |
| Length w/ Screed | 234 in |
Hopper/Paver
| Paving Width - max | 335 in |
|---|---|
| Paving Speed - max | 3.3 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 10.1 mph |
| Auger Diameter | 16 in |
| Paving Thickness - max | 12 in |
