Terex
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
Terex
CR562
- Operating Weight w/ Screed
- 44,315 lb
- Paving Width - max
- 359 in
- Gross Power
- 240.0 hp
- Length w/ Screed
- 251 in
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight w/ Screed | 44,315 lb |
|---|---|
| Operating Weight w/o Screed | 36,415 lb |
| Fuel Capacity | 81.9 gal |
| Hydraulic System Fluid Capacity | 75.1 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 6.7 gal |
| Alternator Supplied Amperage | 105 A |
Engine
| Engine Model | QSB5.9 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 240.0 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Length of Track on Ground | 128 in |
|---|---|
| Transport Width | 125 in |
| Transport Height | 110 in |
| Track Width | 18 in |
| Length w/ Screed | 251 in |
Hopper/Paver
| Paving Width - max | 359 in |
|---|---|
| Paving Speed - max | 2.0 mph |
| Hopper Capacity | 10 lb |
| Travel Speed - max | 9.6 mph |
| Auger Diameter | 16 in |
| Paving Thickness - max | 12 in |
