Terex
Volvo
EC55
Excavator
40 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 16,535 lb |
|---|---|
| Fuel Capacity | 34.4 gal |
| Hydraulic Pump Flow Capacity | 41.0 gal/min |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Hydraulic System Relief Valve Pressure | 4,060 psi |
| Operating Voltage | 12 V |
Engine
| Engine Model | KHD BF 4 M |
|---|---|
| Displacement | 195 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 72.0 hp |
| Number of Cylinders | 4 |
| Engine Make | 2349 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 107 in |
| Tail Swing Radius | 48 in |
| Width to Outside of Tracks | 91 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 3.3 mph |
Boom/Stick Excavator Option 1
| Max Digging Depth | 168 in |
|---|---|
| Max Reach Along Ground | 284 in |
| Max Loading Height | 165 in |
| Max Vertical Wall Digging Depth | 104 in |
| Max Cutting Height | 244 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.50 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 175 in |
|---|---|
| Max Vertical Wall Digging Depth | 110 in |
| Max Cutting Height | 248 in |
| Max Loading Height | 169 in |
| Max Reach Along Ground | 294 in |
